Lifting capacity:
1–200 tons
Compatible host machine:
crane, reach stacker, forklift
In-house engineering, manufacturing & service
Fully custom solutions for specific material handling requirements
For applications that cannot be solved with a modular lifting solution, we develop fully custom solutions. Every project starts with an analysis of the product, handling process, available host machine, and operating conditions. Based on this, our engineers determine the most suitable approach, whether using vacuum technology, mechanical systems, or a combination of both.
Decades of experience in different industries give us a broad view of material handling. This often helps our engineers identify possibilities beyond the initial concept, whether in the handling method, process layout, or level of automation and operator involvement.
With engineering, manufacturing, and service in-house, we cover the complete process — from developing the design and controlling production quality to service and maintenance after delivery.
Key benefits
- Engineered around specific requirements
- Most suitable technology
- Seamless integration into existing operations
- Optimized handling processes
- Reduced risk of product damage
- Enhanced safety
- One partner from concept to production and service
Safety
- Safety factor 2: double the maximum lifting capacity
- Manufactured using ISO 3834-2 certified welding processes
- Remote-controlled handling from a safe distance
- Visual and audible safety indicators
- Alarm system with battery backup
- Minimum 20-minute holding time in case of power failure
- Optional additional safety features available
Ease of use
- No manual attachment of slings, hooks or clamps required
- Remote control with intuitive button layout
- Clear indication when it is safe to lift
- Easy storage when not in use
Technical specifications
- Working Load Limit (WLL): 1-200 tons
- Compatible with existing equipment
- Power supply: electric, battery, hydraulic, diesel
- Operating temperature: -20°C to +40°C
- Suitable for indoor and outdoor use
- CE certified according to EN 13155
Service & maintenance
- Maintenance-oriented design
- In-house developed vacuum components for reliability and durability
- Simple daily inspections completed within minutes
- Clear maintenance documentation and service checklists
- Optional maintenance training upon delivery
- Optional maintenance plan with periodic service visits
- Global availability of spare parts and replacement components
- Worldwide service and technical support
Custom solutions for a wide range of products and industries
Our expertise lies in handling heavy loads from 1 to 200 tons, including precast concrete elements and tunnel segments, metal sheets, and paper rolls. While our modular lifting solutions can be configured for a wide range of applications, we also develop fully customized handling systems for unique requirements or other industries. For instance, our custom solutions include integration with automated precast concrete handling lines, C-hooks and grippers for monopile cans and cones, and ship-to-ship vacuum mooring systems.
Lifting solutions for
-
Titel 3
-
Titel 4
-
Titel 5
Have a question about your handling process?
Discuss your product, handling process and requirements with our Sales Engineer.
We can help you explore the available options.
+31 346 354 333
sales@aerolift.nlstories & Projects
-
- Concrete
Vacuum lifting of precast concrete piles
For Centrum Pile in the United Kingdom, we supplied three identical 16-ton vacuum lifters for handling precast concrete piles at an outdoor storage yard. The machines lift and transport square concrete piles ranging from 3 to 16 metres in length, covering the yard's full range of pile dimensions.
-
- Concrete
Two vacuum tilters for precast concrete handling
Mombarg Beton, a leading precast concrete supplier in the Netherlands, optimized its production process with two Aerolift vacuum tilters for demoulding, lifting, tilting, and moving of precast concrete elements. The tilters can operate independently or in tandem, allowing to handle a wide range of concrete elements with different dimensions and weights.
-
- Customer stories
- Metal
Battery-powered vacuum lifter – the perfect solution for shipyard Royal IHC
If there’s one industry where large and heavy steel plates are used extensively, it’s shipbuilding. The Dutch shipyard Royal IHC in Kinderdijk chose to use an Aerolift vacuum lifter for handling. Bert de Kwant, Technical Services Manager at Royal IHC, explains why.
-
- Customer stories
- Wind energy
Aerolift develops a unique lifting solution for a unique factory
For the production of monopile foundations for the offshore wind industry, Sif chose a factory with unique processes and machines. For the development and production of special lifting solutions, ...
-
- Customer stories
- Metal
Stigterstaal has been satisfied for decades with Aerolift vacuum lifters
Being a global brand, Stigterstaal is a leading steel supplier for the shipbuilding and offshore industries. For decades, the company based near Rotterdam, the Netherlands has used Aerolift...
-
- Concrete
- Customer stories
Vacuum tilters – the solution for Mombarg Beton
Since we started using Aerolift vacuum tilters, the cycle time has greatly reduced. Demoulding is much faster and gentler because the force is distributed over the entire suction pad. As a result, there is...
Planning to purchase a handling solution? Request a quotation
1
Inquiry
Using the contact form below, request a non-binding quotation. We confirm receipt of your inquiry and start the analysis.
2
Calculation
Our engineering team prepares a detailed calculation to determine the most suitable lifting solution.
3
Proposal
You receive a technical proposal and quotation tailored to your needs.
